Production Line Panel Flipper for Sheet Handling

Name: Production Line Panel Flipper for Sheet Handling | HARSLE
SKU: HS202662904-1
Price: 29900 USD
Availability: InStock

O preço original era: $33,000.O preço atual é: $29,900. Definir

The Production Line Panel Flipper is designed to improve efficiency and safety in sheet metal handling processes. It enables quick and controlled flipping of large panels within production lines, reducing manual labor and minimizing material damage. Built for industrial environments, this equipment ensures stable operation, high precision, and seamless integration into automated manufacturing systems. Ideal for metal fabrication workshops and large-scale production facilities, it enhances workflow efficiency and supports continuous, high-volume production requirements.

100 em estoque

Observação: Os preços variam conforme o modelo e a configuração. Clique em "Enviar consulta" para obter um orçamento personalizado.

Comparar

Adicionar à lista de desejos

ENVIAR CONSULTA

Painel giratório

Item	Unidade	AutoFlip 1200	AutoFlip 1600	AutoFlip 2000
Comprimento máximo de curvatura	mm	1200	1600	2000
Largura Máxima de Curvatura	mm	600	600	600
Altura máxima de flexão	mm	80	80	80
MS	mm	1.2	1.2	1.2
SS	mm	0.6	0.6	0.6
AL	mm	1.5	1.5	1.5
Min. Bending Thickness	mm	0.3	0.3	0.3
Raio de curvatura mínimo	mm	2	2	2
Range of Folding Angles	°	0-120	0-120	0-120
Angular Accuracy	°/m	±1	±1	±1
Bend Dimensional Accuracy	mm/m	±0,1	±0,1	±0,1
Working Accuracy	mm	0.001	0.001	0.001
Velocidade de dobra	s/dobra	0.2	0.2	0.2
Operating Noise	dB	50	50	50
Air Supply Pressure	Mpa	0.5	0.5	0.5
Total Number of Controlled Axes	-	7	7	7
User Operating Environment	-	win10	win10	win10
Min. Inside Size (Four-Side)	mm	150*80	150*80	150*120
Min. Inside Size ( Double-Side)	mm	80	80	120
Potência média de trabalho	KW	1.5	1.8	2.1
Comprimento	mm	2500	3200	4500
Largura	mm	1800	2200	2300
Altura	mm	2100	2100	2100

8 Pessoas que estão assistindo a este produto agora!

Descrição

The Production Line Panel Flipper is an essential automation solution for modern sheet metal manufacturing and assembly lines. It is engineered to safely and efficiently flip large metal panels during production processes, significantly reducing manual handling risks and improving overall workflow efficiency. With a robust structure and reliable hydraulic or mechanical system, it ensures stable and precise operation even under continuous industrial use.

This equipment is widely used in metal fabrication plants, appliance manufacturing, automotive production, and heavy industrial workshops where large sheet handling is required. By integrating the panel flipper into production lines, manufacturers can reduce labor costs, increase throughput, and improve workplace safety.

The system is designed for easy integration with existing production lines and can be customized based on panel size, weight capacity, and workflow requirements. Its smooth and controlled flipping mechanism ensures no surface damage during operation.

Principais características:

Efficient and safe flipping of large sheet metal panels
Heavy-duty structure for continuous industrial operation
Reduces manual labor and improves workplace safety
Compatible with automated production line systems
Customizable for different panel sizes and load capacities
Smooth hydraulic/mechanical flipping mechanism
Enhances productivity and reduces production downtime
Suitable for automotive, appliance, and metal fabrication industries

With its advanced design and reliable performance, the Production Line Panel Flipper is a critical component for manufacturers aiming to improve automation, efficiency, and safety in modern sheet metal production environments.

Perguntas mais populares

What is the AutoFlip Panel Flipper and how does it work?

The AutoFlip Panel Flipper is an automated sheet metal turnover machine designed to rotate heavy flat panels safely and precisely. The workpiece is placed on the flipper table and secured by adjustable clamps or a vacuum/suction system. A hydraulic or servo-driven mechanism then rotates the panel through 90° or 180° in a controlled motion. The entire cycle is completed in seconds with a single operator command — eliminating the need for cranes, slings, or manual repositioning.

Why is an automated panel flipper safer than manual turning methods?

Manual flipping with cranes, forklifts, or chains is physically demanding, time-consuming, and carries a high risk of dropped loads, pinch-point injuries, and surface damage. The AutoFlip Panel Flipper keeps the operator at a safe distance while the machine performs a smooth, synchronized rotation. Built-in safety interlocks, emergency stops, and mechanical position locks ensure the panel remains securely held throughout the entire flip cycle.

What types of panels and materials can the AutoFlip handle?

The AutoFlip Panel Flipper is built for a wide range of flat workpieces, including laser-cut, plasma-cut, and flame-cut steel sheets, stainless steel panels, aluminum plates, welded assemblies, electrical enclosures, and structural frames. It handles both individual panels and stacked sheet bundles. Optional rubber mats, nylon brushes, or felt linings can be fitted to protect pre-painted, powder-coated, or polished surfaces during rotation.

What are the load capacity and maximum panel size specifications?

We offer AutoFlip Panel Flipper models with load capacities from 750 kg up to 5,000 kg, with custom heavy-duty configurations available for loads exceeding 10 tons. Standard table sizes accommodate panels up to 1,200 × 800 mm, while extended models support panels up to 3,000 × 1,500 mm or larger upon request. Material thickness typically ranges from 0.5 mm thin sheets to 50 mm heavy plates, depending on the model selected.

Can the AutoFlip rotate panels to custom angles, not just 180°?

Yes. While 180° full turnover is the most common operation, the AutoFlip Panel Flipper supports programmable rotation to any angle between 0° and 180°, including 90° vertical-to-horizontal transitions. The hydraulic system maintains pressure at intermediate stop positions, allowing the panel to be held securely at the desired angle for welding, inspection, or machining access on both sides without additional support fixtures.

Where can the AutoFlip Panel Flipper be integrated in a production line?

The AutoFlip integrates seamlessly into sheet metal fabrication workflows — positioned between laser or plasma cutting and folding/bending stations, alongside welding cells for double-sided access, or at quality inspection points for top-and-bottom surface checks. It can be connected to roller conveyors, belt transfer systems, or robotic loading/unloading units for fully automated inline operation with minimal manual intervention.

Does the AutoFlip protect delicate or coated panel surfaces during flipping?

Absolutely. The flipper table surface can be equipped with replaceable rubber pads, nylon brushes, or soft felt covers to prevent scratching on painted, galvanized, brushed, or mirror-finish panels. Adjustable clamping pressure and vacuum suction options distribute holding force evenly across the panel surface. The smooth, vibration-free hydraulic drive ensures no impact or sudden jerking that could dent or mar the workpiece.

How long does a typical flip cycle take?

Cycle time depends on the model and rotation angle. Pneumatic AutoFlip models complete a 180° flip in approximately 5–10 seconds, making them ideal for high-frequency turnover tasks. Hydraulic models handling heavier loads typically complete a full rotation in 35–60 seconds. Compared to manual crane-based flipping that can take 5–15 minutes per panel, the AutoFlip dramatically reduces downtime and frees operators for other tasks.

What safety features are included with the AutoFlip Panel Flipper?

Every AutoFlip Panel Flipper is equipped with emergency stop buttons, mechanical and hydraulic position locks, synchronized cylinder operation to prevent tilting imbalance, and automatic pressure-hold at any stop angle. Optional safety fencing, light curtains, and two-hand control panels are available for enhanced operator protection. All units comply with CE safety standards and include automatic soft-reset and position-lock functions in case of power interruption.

What is the lead time, warranty, and after-sales support?

Standard production lead time is 15–30 working days for common models, with custom configurations requiring 30–45 days. We provide a 12-month warranty covering manufacturing defects, along with free lifetime technical support. Our after-sales team offers remote diagnostics, spare parts supply, on-site installation and commissioning, operator training, and preventive maintenance programs to keep your AutoFlip running at peak performance.
