Flat Metal Deburring Machines for Sheet Processing
Original price was: $5,600.$4,800Current price is: $4,800.Set
Slag Removal Tool for Laser Cut Metal Parts
Original price was: $1,680.$1,450Current price is: $1,450.Set
Magnetic Deburring Polishing Machine for Laser Cut Parts
Original price was: $5,600.$4,800Current price is: $4,800.Set
The magnetic deburring polishing machine is specially designed for finishing sheet metal parts after laser cutting. It efficiently removes burrs, sharp edges, and oxidation from laser-cut components using high-speed magnetic force and stainless steel polishing needles. This process improves edge smoothness and surface quality without damaging the workpiece. Ideal for stainless steel, aluminum, and other metal sheets, the machine helps manufacturers achieve clean, safe, and professional finishes for laser-cut parts.
100 in stock
Note: Prices vary by model and configuration. Click "Send Inquiry" for a customized quote.
FlatPolish
| Item | Unit | DM630 | DM1000 | DV630 | DV1000 | DMV630 | DMV1000 |
| Processing Width | mm | 630 | 1000 | 630 | 1000 | 630 | 1000 |
| Processing Thickness | mm | 0.5-100 | 0.5-100 | 0.5-100 | 0.5-100 | 0.5-100 | 0.5-100 |
| Minimum Workpiece Size | mm | โฅ30*30*0.5 | โฅ30*30*0.5 | โฅ30*30*0.5 | โฅ30*30*0.5 | โฅ30*30*0.5 | โฅ30*30*0.5 |
| Feeding Speed | m/min | 0.5-14 | 0.5-14 | 0.5-14 | 0.5-14 | 0.5-14 | 0.5-14 |
| Abrasive Belt Size | mm | 2000*630 | 2000*1000 | 2000*630 | 2000*1000 | 2000*630 | 2000*1000 |
| Working Table Height | mm | 860-980 | 860-980 | 860-980 | 860-980 | 860-980 | 860-980 |
| Main Grinding Roller Diameter | mm | 190 | 190 | 190 | 190 | 190 | 190 |
| Abrasive Belt Motor | kw | 7.5*2 | 15+11 | 7.5*2 | 15+11 | 7.5*2 | 15+11 |
| Conveyor Motor | kw | 1.1 | 1.5 | 1.1 | 1.5 | 1.1 | 1.5 |
| Table Lifting Motor | kw | 0.37 | 0.37 | 0.37 | 0.37 | 0.37 | 0.37 |
| Negative Pressure Fan Motor | kw | - | - | 7.5 | 11 | 7.5 | 11 |
| Negative Pressure Fan Dimensions | mm | - | - | 1000*980*850 | 1200*850*1000 | 1000*980*850 | 1200*850*1000 |
| Negative Pressure Fan Weight | kg | - | - | 180 | 220 | 180 | 220 |
| Overall Dimensions | mm | 1800*1150*2050 | 1850*1550*2050 | 1800*1150*2050 | 1850*1550*2050 | 1800*1150*2050 | 1850*1550*2050 |
| Machine Weight | kg | 1100 | 1400 | 1100 | 1400 | 1100 | 1400 |
7
People watching this product now!
Description
The magnetic deburring polishing machine is an efficient surface finishing solution designed specifically for processing sheet metal parts after laser cutting. Laser-cut components often produce small burrs, micro sharp edges, and oxidation layers that can affect product appearance, assembly accuracy, and operator safety. This machine provides a fast and consistent method to remove those imperfections and improve the overall surface quality of metal parts.
The system generates a powerful rotating magnetic field that drives stainless steel polishing needles to move at high speed around the workpieces. These needles reach narrow edges, small holes, and complex contours, ensuring uniform deburring and polishing even in difficult areas that traditional grinding tools cannot access.
This machine is widely used in sheet metal fabrication workshops, especially in production lines that include laser cutting, stamping, or CNC machining processes. It is particularly suitable for processing stainless steel, aluminum, brass, copper, and other metal sheets commonly used in industrial manufacturing.
Compared with manual deburring, the magnetic polishing process significantly improves efficiency, ensures consistent finishing quality, and reduces labor costs. It is an ideal solution for manufacturers seeking automated finishing after laser cutting.
Key Features
-
Perfect for Laser-Cut Parts
Efficiently removes burrs and sharp edges from laser-cut sheet metal components. -
Uniform Edge Finishing
Magnetic needles reach complex shapes and internal areas for complete deburring. -
Improved Surface Quality
Removes oxidation and polishing marks while maintaining material integrity. -
Automated & Efficient Process
Reduces manual polishing time and improves production efficiency. -
Wide Material Compatibility
Suitable for stainless steel, aluminum, copper, and various sheet metal parts.
The magnetic deburring polishing machine helps manufacturers achieve clean edges, safer parts, and higher-quality finished products after laser cutting operations.
WHAT WE OFFER
Product Features Overview
Holding
The workpiece is securely fixed by magnetic or vacuum holding to ensure stable positioning during processing.
Deburring
Abrasive belts remove burrs or sharp edges, deliveing uniform surface and edge quality.
Discharge
The finished workpiece is automatically conveyed out of the machine, ready for the next production step.
Magnetic Conveyor
Designed for ferrous workpieces such as carbon steel and other magnetic, the magnetic conveyor belt securely holds parts during processing.
Magnetic & Vacuum Conveyor*
This combined system is ideal for mixed material applications, handing both magnetic and non-magnetic workpieces on the same line.
Vacuum Conveyor*
The vacuum conveyor belt is suitable for non-magnetic materials such as aluminum and copper. By using vacuum suction.
Why Choose HARSLE
Direct Manufacturer
Factory direct, no middlemen, ensuring the best prices for our customers.
3-Year Warranty
Enjoy peace of mind with a three-year warranty and free parts replacement.
Multilingual Support
Our multilingual team ensures efficient communication for all your needs.
Timely Delivery
The machines are delivered on time, ensuring our customers receive them promptly.
Quality Assurance
Comprehensive quality checks guarantee the quality of every machine.
Localized Service
We provide prompt, localized service in multiple countries for your convenience.
Trusted Global Partners
Our valued partners span industries worldwide, contributing to innovative solutions and mutual growth. Weโre proud to collaborate with these esteemed brands, enhancing service quality and expanding our global presence in metalworking technology.
Testimonials
Hear What Our Customers Say
At HARSLE, we believe in the power of collaboration. Our trusted partnerships with leading brands in the metalworking industry enhance our capabilities and expand our offerings. Together, we strive to deliver innovative solutions that meet the evolving needs of our clients. These partnerships not only allow us to share knowledge and expertise but also ensure that we provide high-quality machines and services. Our commitment to excellence is reflected in the strong relationships we have built, which ultimately benefit our customers. Join us in celebrating our valued partners who share our vision for quality and innovation.
★★★★★ Classificado como 5 de 5
Exceptional Quality and Performance!
Perfect edge rounding without compromising tolerances. The consistent finish is impressive. Plus, the dust extraction system keeps our workshop clean and healthy. Great for quality and employee safety!
Germany
★★★★★ Classificado como 5 de 5
Outstanding Service Every Time!
Throughput tripled instantly! The dual-sided processing saves immense time. We achieved 300% faster speeds, and labor savings covered the investment in six months. Perfect for high-volume production.
USA
Most Popular Questions
What is a metal deburring machine and how does it work?
A metal deburring machine is designed to remove burrs, sharp edges, slag, and oxide layers from metal parts after cutting, punching, or laser processing. It works by passing workpieces through a series of rotating abrasive brushes, sanding belts, or grinding heads that uniformly smooth all edges and surfaces. The result is clean, safe-to-handle parts with consistent edge quality.
What types of metal deburring machines do you offer?
We offer a full range of metal deburring machines, including sheet metal deburring machines, edge rounding machines, slag removal machines, oxide layer removal machines, and multi-function models that combine deburring, edge rounding, and surface finishing in a single pass. Both wide-belt and planetary head configurations are available to suit different application requirements.
What materials can your deburring machines process?
Our metal deburring machines can process a wide variety of materials including carbon steel, stainless steel, aluminum, copper, brass, galvanized steel, and titanium. They are suitable for parts produced by laser cutting, plasma cutting, flame cutting, stamping, punching, and shearing. The machines handle both thin sheets and medium-thick plates effectively.
What is the maximum working width and thickness capacity?
Our deburring machines are available in working widths from 600 mm to 1,600 mm, with workpiece thickness capacities ranging from 0.5 mm to 80 mm depending on the model. The minimum part size is typically 50 mm ร 50 mm. We can recommend the optimal machine specification based on your part dimensions and production volume.
Can the machine deburr both sides of a part in one pass?
Yes, our dual-sided deburring machines are equipped with processing units on both the top and bottom, allowing simultaneous deburring and edge rounding on both sides of the workpiece in a single pass. This significantly reduces processing time and eliminates the need to flip parts manually, greatly improving production efficiency and consistency.
What are the advantages of using a deburring machine over manual deburring?
Machine deburring offers significant advantages over manual methods: uniform and repeatable edge quality, dramatically faster processing speed (up to 10ร faster), reduced labor costs, improved workplace safety by eliminating hand grinding, and consistent results regardless of operator skill level. Automated deburring also minimizes the risk of part damage and ensures every piece meets the same quality standard.
How does the edge rounding function work?
The edge rounding function uses specially designed abrasive brushes or planetary grinding heads to create a uniform radius on all edges of the workpiece. The rounding radius is adjustable, typically from R0.2 mm to R2.0 mm, to meet different coating and safety requirements. Rounded edges improve paint and powder coating adhesion, prevent coating failure at sharp corners, and make parts safe to handle.
What maintenance is required for the deburring machine?
Routine maintenance mainly involves replacing abrasive belts and brushes when worn, cleaning the dust collection system, and periodic lubrication of mechanical components. Consumable replacement is straightforward and can be done by operators without special tools. We provide maintenance guidelines and recommended replacement schedules to ensure your machine maintains optimal performance with minimal downtime.
What is the typical lead time and warranty period?
The standard production lead time for our metal deburring machines is 15 to 30 days depending on the model and configuration. We provide a 12-month warranty covering manufacturing defects on the entire machine, with extended warranty options available. Spare parts, technical support, and consumable supplies are readily accessible throughout the machine's lifetime.
Do you provide installation, training, and after-sales support?
Yes, we offer comprehensive installation and commissioning services, hands-on operator training, and long-term after-sales support. Our engineers can provide on-site setup or remote guidance via video. We also supply detailed operation manuals, maintenance training, and fast spare parts delivery to ensure your deburring machine operates at peak efficiency throughout its service life.
Additional information
| Weight | 999 kg |
|---|---|
| Dimensions | 2020 × 1750 mm |
| Brand | HARSLE |
| Lead Time | 45 Days |
| Function | Deburring |
| Price Term | EXW |
| Warranty | 1 Year |
| Payment Term | LC, TT |
