Chamfering and Deburring Machine for Laser Cutting Applications

Name: Chamfering and Deburring Machine for Laser Cutting Applications | HARSLE
SKU: HS20261264
Price: 10800 USD
Availability: InStock

Original price was: $12,600.Current price is: $10,800.Set

A chamfering and deburring machine is designed to remove sharp edges, burrs, and corner imperfections after cutting or machining. It ensures smooth, safe, and high-quality metal parts for further processing or assembly. Widely used in sheet metal fabrication, laser cutting, punching, and shearing lines, this machine improves surface finish, enhances operator safety, and increases overall production efficiency. It is suitable for steel, stainless steel, aluminum, and other metal materials.

100 in stock

Note: Prices vary by model and configuration. Click "Send Inquiry" for a customized quote.

Compare

Add to wishlist

SEND INQUIRY

DualPolish

Item	Unite	SM630	SM1000	SM1300	SV630	SV1000	SV1300	SMV630	SMV1000	SMV1300	DM630	DM1000	DM1300	DV630	DV1000	DV1300	DMV630	DMV1000	DMV1300
Processing Width	mm	630	1000	1300	630	1000	1300	630	1000	1300	630	1000	1300	630	1000	1300	630	1000	1300
Processing Thickness	mm	0.5-100	0.5-100	0.5-100	0.5-100	0.5-100	0.5-100	0.5-100	0.5-100	0.5-100	0.5-100	0.5-100	0.5-100	0.5-100	0.5-100	0.5-100	0.5-100	0.5-100	0.5-100
Minimum Workpiece Size	mm	≥30100.5	≥50500.5	≥50500.5	≥50500.5	≥50500.5	≥50500.5	≥50500.5	≥50500.5	≥50500.5	≥30100.5	≥50500.5	≥50500.5	≥50500.5	≥50500.5	≥50500.5	≥50500.5	≥50500.5	≥50500.5
Feeding Speed	m/min	0.5-14	0.5-14	0.5-14	0.5-14	0.5-14	0.5-14	0.5-14	0.5-14	0.5-14	0.5-14	0.5-14	0.5-14	0.5-14	0.5-14	0.5-14	0.5-14	0.5-14	0.5-14
Roller Brush Speed	m/min	8-20	8-20	8-20	8-20	8-20	8-20	8-20	8-20	8-20	8-20	8-20	8-20	8-20	8-20	8-20	8-20	8-20	8-20
Orbital Speed	m/min	8-12	8-12	8-12	8-12	8-12	8-12	8-12	8-12	8-12	8-12	8-12	8-12	8-12	8-12	8-12	8-12	8-12	8-12
Abrasive Belt Size	mm	2000*630	2000*1000	2200*1300	2000*630	2000*1000	2200*1300	2000*630	2000*1000	2200*1300	2000*630	2000*1000	2200*1300	2000*630	2000*1000	2200*1300	2000*630	2000*1000	2200*1300
Abrasive Wheel Size	mm	Φ300X200X24	Φ350X300X28	Φ350X300X35	Φ300X200X24	Φ350X300X28	Φ350X300X35	Φ300X200X24	Φ350X300X28	Φ350X300X35	Φ300X200X24	Φ350X300X28	Φ350X300X35	Φ300X200X24	Φ350X300X28	Φ350X300X35	Φ300X200X24	Φ350X300X28	Φ350X300X35
Main Grinding Roller Diameter	mm	190	190	210	190	190	210	190	190	210	190	190	210	190	190	210	190	190	210
Working Table Height	mm	860-980	860-980	860-980	860-980	860-980	860-980	860-980	860-980	860-980	860-980	860-980	860-980	860-980	860-980	860-980	860-980	860-980	860-980
Orbital Motor	kw	0.75	0.75	0.75	0.75	0.75	0.75	0.75	0.75	0.75	0.75	0.75	0.75	0.75	0.75	0.75	0.75	0.75	0.75
Roller Brush Motor	kw	2.2*2	2.2*3	2.2*3	2.2*2	2.2*3	2.2*3	2.2*2	2.2*3	2.2*3	2.2*2	2.2*3	2.2*3	2.2*2	2.2*3	2.2*3	2.2*2	2.2*3	2.2*3
Abrasive Belt Motor	kw	7.5	15	22	7.5	15	22	7.5	15	15	7.5	15+11	15	7.5	15+11	22	7.5	15+11	15
Conveyor Motor	kw	2.2	3	3	2.2	3	3	2.2	3	3	2.2	4	3	2.2	3	3	2.2	3	3
Brush Lifting Motor	kw	0.55	0.55	0.55	0.55	0.55	0.55	0.55	0.55	0.55	0.55	0.55	0.55	0.55	0.55	0.55	0.55	0.55	0.55
Table Lifting Motor	kw	0.55	0.55	0.55	0.55	0.55	0.55	0.55	0.55	0.55	0.55	0.55	0.55	0.55	0.55	0.55	0.55	0.55	0.55
Chamfering Range	mm	R0.1-1	R0.1-1	R0.1-1	R0.1-1	R0.1-1	R0.1-1	R0.1-1R0.1-1	R0.1-1	R0.1-1	R0.1-1	R0.1-1	R0.1-1	R0.1-1	R0.1-1	R0.1-1	R0.1-1	R0.1-1	R0.1-1
Negative Pressure Fan	kw	-	-	-	7.5	15	15	7.5	11	15	-	-	-	7.5	15	15	7.5	15	15
Negative Pressure Fan Dimensions	mm	-	-	-	1000980850	13509001150	13509001150	1000980850	12008501000	13509001150	-	-	-	1000980850	13509001150	13509001150	1000980850	13509001150	13509001150
Negative Pressure Fan Weight	kg	-	-	-	180	260	260	180	220	260	-	-	-	180	280	260	180	280	260
Machine Dimensions	mm	235011502300	350011502300	380019002350	235011502300	350011502300	380019002350	235011502300	350011502300	380019002350	285011502300	350011502300	380019002350	285011502300	350011502300	380019002350	285011502300	350011502300	380019002350
Machine Weight	kg	1600	2200	3000	1600	2200	3000	1600	2200	3000	1800	2400	3000	1800	2400	3000	1800	2400	3000

9 People watching this product now!

Description

A chamfering and deburring machine plays a critical role in modern metal fabrication by eliminating sharp edges, burrs, and uneven corners left after cutting processes such as laser cutting, plasma cutting, punching, or shearing. Without proper deburring, metal parts can pose safety risks, reduce assembly accuracy, and negatively affect coating or welding quality. This machine provides a fast, consistent, and automated solution for edge finishing.

Designed for both small workshops and large-scale production lines, a chamfering and deburring machine delivers uniform chamfer angles and smooth edges on flat metal sheets and plates. It significantly reduces manual grinding work, shortens processing time, and ensures stable finishing quality across batches. With adjustable settings, operators can easily control chamfer depth and deburring intensity to match different materials and thicknesses.

The machine is commonly used in industries such as sheet metal fabrication, electrical cabinets, elevator manufacturing, automotive components, and general metal processing. Its robust structure, efficient dust extraction compatibility, and user-friendly operation make it an essential finishing solution for manufacturers seeking higher quality standards.

Key Features:

Efficient removal of burrs and sharp edges after cutting
Uniform chamfering for improved appearance and assembly accuracy
Suitable for steel, stainless steel, aluminum, and other metals
Adjustable chamfer depth for different thicknesses and applications
High processing efficiency, ideal for batch production
Reduces manual labor and improves operator safety

Trusted Global Partners

Our valued partners span industries worldwide, contributing to innovative solutions and mutual growth. We’re proud to collaborate with these esteemed brands, enhancing service quality and expanding our global presence in metalworking technology.

Chamfering and Deburring Machine for Laser Cutting Applications

Why Choose HARSLE

Direct Manufacturer

Factory direct, no middlemen, ensuring the best prices for our customers.

3-Year Warranty

Enjoy peace of mind with a three-year warranty and free parts replacement.

Multilingual Support

Our multilingual team ensures efficient communication for all your needs.

Timely Delivery

The machines are delivered on time, ensuring our customers receive them promptly.

Quality Assurance

Comprehensive quality checks guarantee the quality of every machine.

Localized Service

We provide prompt, localized service in multiple countries for your convenience.

WHAT WE OFFER

Product Features Overview

Testimonials

Hear What Our Customers Say

At HARSLE, we believe in the power of collaboration. Our trusted partnerships with leading brands in the metalworking industry enhance our capabilities and expand our offerings. Together, we strive to deliver innovative solutions that meet the evolving needs of our clients. These partnerships not only allow us to share knowledge and expertise but also ensure that we provide high-quality machines and services. Our commitment to excellence is reflected in the strong relationships we have built, which ultimately benefit our customers. Join us in celebrating our valued partners who share our vision for quality and innovation.

Rated 5 out of 5

Exceptional Quality and Performance!

Perfect edge rounding without compromising tolerances. The consistent finish is impressive. Plus, the dust extraction system keeps our workshop clean and healthy. Great for quality and employee safety!

Rosetta Capristo

Germany

Rated 5 out of 5

Outstanding Service Every Time!

Throughput tripled instantly! The dual-sided processing saves immense time. We achieved 300% faster speeds, and labor savings covered the investment in six months. Perfect for high-volume production.

Mario Gurrola

USA

Most Popular Questions

What is a metal deburring machine and how does it work?

A metal deburring machine is designed to remove burrs, sharp edges, slag, and oxide layers from metal parts after cutting, punching, or laser processing. It works by passing workpieces through a series of rotating abrasive brushes, sanding belts, or grinding heads that uniformly smooth all edges and surfaces. The result is clean, safe-to-handle parts with consistent edge quality.

What types of metal deburring machines do you offer?

We offer a full range of metal deburring machines, including sheet metal deburring machines, edge rounding machines, slag removal machines, oxide layer removal machines, and multi-function models that combine deburring, edge rounding, and surface finishing in a single pass. Both wide-belt and planetary head configurations are available to suit different application requirements.

What materials can your deburring machines process?

Our metal deburring machines can process a wide variety of materials including carbon steel, stainless steel, aluminum, copper, brass, galvanized steel, and titanium. They are suitable for parts produced by laser cutting, plasma cutting, flame cutting, stamping, punching, and shearing. The machines handle both thin sheets and medium-thick plates effectively.

What is the maximum working width and thickness capacity?

Our deburring machines are available in working widths from 600 mm to 1,600 mm, with workpiece thickness capacities ranging from 0.5 mm to 80 mm depending on the model. The minimum part size is typically 50 mm × 50 mm. We can recommend the optimal machine specification based on your part dimensions and production volume.

Can the machine deburr both sides of a part in one pass?

Yes, our dual-sided deburring machines are equipped with processing units on both the top and bottom, allowing simultaneous deburring and edge rounding on both sides of the workpiece in a single pass. This significantly reduces processing time and eliminates the need to flip parts manually, greatly improving production efficiency and consistency.

What are the advantages of using a deburring machine over manual deburring?

Machine deburring offers significant advantages over manual methods: uniform and repeatable edge quality, dramatically faster processing speed (up to 10× faster), reduced labor costs, improved workplace safety by eliminating hand grinding, and consistent results regardless of operator skill level. Automated deburring also minimizes the risk of part damage and ensures every piece meets the same quality standard.

How does the edge rounding function work?

The edge rounding function uses specially designed abrasive brushes or planetary grinding heads to create a uniform radius on all edges of the workpiece. The rounding radius is adjustable, typically from R0.2 mm to R2.0 mm, to meet different coating and safety requirements. Rounded edges improve paint and powder coating adhesion, prevent coating failure at sharp corners, and make parts safe to handle.

What maintenance is required for the deburring machine?

Routine maintenance mainly involves replacing abrasive belts and brushes when worn, cleaning the dust collection system, and periodic lubrication of mechanical components. Consumable replacement is straightforward and can be done by operators without special tools. We provide maintenance guidelines and recommended replacement schedules to ensure your machine maintains optimal performance with minimal downtime.

What is the typical lead time and warranty period?

The standard production lead time for our metal deburring machines is 15 to 30 days depending on the model and configuration. We provide a 12-month warranty covering manufacturing defects on the entire machine, with extended warranty options available. Spare parts, technical support, and consumable supplies are readily accessible throughout the machine's lifetime.

Do you provide installation, training, and after-sales support?

Yes, we offer comprehensive installation and commissioning services, hands-on operator training, and long-term after-sales support. Our engineers can provide on-site setup or remote guidance via video. We also supply detailed operation manuals, maintenance training, and fast spare parts delivery to ensure your deburring machine operates at peak efficiency throughout its service life.
