Part 1 Fill The Oil and Cable Connections

Guillotine shearing tutorial

Filling the oil tank with anti-wear hydraulic oil. And fill the oil from this port.

Guillotine shearing tutorial

Connect to a 3-phase power source.

Guillotine shearing tutorial

Guillotine shearing tutorial

Guillotine shearing tutorial

Switch on the power source.

Guillotine shearing tutorial

Guillotine shearing tutorial

Turn On the Machine Power Switch

Guillotine shearing tutorial

Connect the pedal switch to the machine.

Guillotine shearing tutorial

Turn on the power switch.

Guillotine shearing tutorial

Release the emergency stop button and start the oil pump

Guillotine shearing tutorial

Check the main motor’s rotating direction.

Guillotine shearing tutorial

If it rotates clockwise, then it is correct.

Guillotine shearing tutorial

If it is rotating anti-clockwise.

Guillotine shearing tutorial

Press the emergency stop.

Guillotine shearing tutorial

Exchange the two wires connection.

Guillotine shearing tutorial

Guillotine shearing tutorial

Part 2 Machine Start-up

Guillotine shearing tutorial

Turn on the machine power switch.

Guillotine shearing tutorial

Turn on the power control key

Guillotine shearing tutorial

Release the emergency stop switch, Start the oil pump.

Guillotine shearing tutorial

Waiting For the System Loading

Guillotine shearing tutorial

Part 3 System Operation

Guillotine shearing tutorial

In Single mode

Guillotine shearing tutorial

Manual movement

Click and enter the manual page

Guillotine shearing tutorial

Guillotine shearing tutorial

Guillotine shearing tutorial

Guillotine shearing tutorial

Guillotine shearing tutorial

Click and operate at low speed in increasing or decreasing directions.

Guillotine shearing tutorial

Move the cursor to the XP value

Guillotine shearing tutorial

Input 100 and confirm

Guillotine shearing tutorial

Click the Run button

Guillotine shearing tutorial

In continuous mode

Guillotine shearing tutorial

Click the P buttom, select or input the program serial number and click

Guillotine shearing tutorial

Guillotine shearing tutorial

Input the Program step to be 3, and click

Guillotine shearing tutorial

Click and enter the first step setup page

Guillotine shearing tutorial

Select XP, input 150, and confirm.

Guillotine shearing tutorial

Click and enter the second step setup page

Guillotine shearing tutorial

Select XP, input 100, and confirm

Guillotine shearing tutorial

Click and enter the third step setup page

Guillotine shearing tutorial

Select XP, input 120, and confirm.

Guillotine shearing tutorial

Click the Run button

Guillotine shearing tutorial

Part 4 Cutting

Guillotine shearing tutorial

In Single mode

Guillotine shearing tutorial

Placing the metal sheet.

Guillotine shearing tutorial

The sheet will touch the stop fingers.

Guillotine shearing tutorial

Step the pedal switch and cutting

Guillotine shearing tutorial

Part 5 Measurement

Guillotine shearing tutorial

Measurement of raw sheet length 455

Guillotine shearing tutorial

Measure the sheet after cutting 355

Guillotine shearing tutorial

Part 6 Maintenance

Guillotine shearing tutorial

The blade holder of the guillotine shear no longer cuts the plate nor can it move up, and there is no response when stepping on the foot switch.

Guillotine shearing tutorial

Open the ball valve and observe the pressure gauge of the accumulator

Guillotine shearing tutorial

Guillotine shearing tutorial

Another employee needs to press and hold the refilling button

Guillotine shearing tutorial

After observing the accumulator pressure gauge rise to about 10. Close the ball valve and stop pressing the fill button at the same time. At this point, the blade holder should have been successfully lifted. The guillotine shear returns to normal operation.

Guillotine shearing tutorial

Guillotine shearing tutorial

Guillotine shearing tutorial

Guillotine shearing tutorial

Part 7 Switch Off

Guillotine shearing tutorial

Press the red Stop button

Guillotine shearing tutorial

Press the emergency stop buttons.

Guillotine shearing tutorial

Turn off the power switch.

Guillotine shearing tutorial
