Smart Press Brake Operation Tutorial For DA-53T

Views: 1020     Author: Site Editor     Publish Time: 2022-06-21      Origin: Site

Inquire

facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button

Applicable for Smart Type DELEM DA-53T

Operation Tutorial DA53T

HARSLE has recorded a detailed operating tutorial of the Smart Press Brake DA-53T to help the new customer to use our press brake faster and better. This tutorial records from oil injection to switch off, it also shows some specific functions of DELEM DA-53T. We hope this will be helpful to you;


Part 1 Fill Oil + Cable Connections

Filling the oil tank with anti-wear hydraulic oil.

Operation Tutorial DA53T

No less than Two-thirds of the Oil Volume Level.

Operation Tutorial DA53T

Connect the machine to the power source.

Operation Tutorial DA53T

Connect the cable to the electrical box.

Operation Tutorial DA53T

Connect the earth wire.

Operation Tutorial DA53T

Switch on the power source.

Operation Tutorial DA53T

Connect the pedal switch to the machine.

Operation Tutorial DA53T

Turn on the machine power switch.

Operation Tutorial DA53T

Waiting for the system loading.

Operation Tutorial DA53T

Check the main motor's rotating direction. Pull down the soft buttons.

Operation Tutorial DA53T

 Press the pump-start button shortly.

Operation Tutorial DA53T

Check the main motor's rotating direction. If it rotates clockwise, then It is correct. If it is rotating anti-clockwise, exchange the two wires' connection.

Operation Tutorial DA53T


Part 2 Machine Start-up

Turn on the machine power switch.

Operation Tutorial DA53T

Waiting for the system loading.

Operation Tutorial DA53T

Operation Tutorial DA53T

Pull down the soft buttons.

Operation Tutorial DA53T

Turn on the lights.

Operation Tutorial DA53T

Press the pump-start button.

Operation Tutorial DA53T

Press the start button and find reference points.

Operation Tutorial DA53T

Finding reference points is done.

Operation Tutorial DA53T

Test the X-axis running.

Operation Tutorial DA53T

Test the R-axis running.

Operation Tutorial DA53T

Test the crowning system running.

Operation Tutorial DA53T

Check the tooling parameters.

Operation Tutorial DA53T

Measure the tooling to compare with the data.

Operation Tutorial DA53T

Part 3 Bending Programming

Input the password 42.

Operation Tutorial DA53T

Input the product ID.

Operation Tutorial DA53T

Input the sheet thickness.

Operation Tutorial DA53T

Selecting the tooling.

Operation Tutorial DA53T

Input the bending length.

Operation Tutorial DA53T

Input the bending angle.

Operation Tutorial DA53T

Enter the X-axis distance.

Operation Tutorial DA53T

Add the second bending step.

Operation Tutorial DA53T

Check program data.

Operation Tutorial DA53T

Ready to start.

Operation Tutorial DA53T


Part 4 Bending Products

Place the metal sheet. The sheet will touch the stop fingers.

Operation Tutorial DA53T

Step the pedal.

Operation Tutorial DA53T

Complete Step one.

Operation Tutorial DA53T

Press the pedal.

Operation Tutorial DA53T

Complete Step two.

Operation Tutorial DA53T



Part 5 Measurement And Calibration

Measure the first bending distance.

Operation Tutorial DA53T

Measure the second bending distance.

Operation Tutorial DA53T

Using the angle ruler. Measure the bending angles in three positions: left, middle, and right.

Operation Tutorial DA53T

Error found. Measured at 91°.

Operation Tutorial DA53T

Enter the calibration parameters -1.

Operation Tutorial DA53T

Bend again for testing.

Operation Tutorial DA53T

Measure again.

Operation Tutorial DA53T

It is correct now.

Operation Tutorial DA53T


Part 6 Other Functions

Laser Protection

Input 01 to open laser protection.

Operation Tutorial DA53T

The slider will brake immediately once the laser is blocked.

Operation Tutorial DA53T

Input 00 to close laser protection.

Operation Tutorial DA53T

The slider will run normally even if the laser is blocked.

Operation Tutorial DA53T

Pedal Control ModeSwitch

Pull down the soft buttons. Click the blue button to open the Jog Mode.

Operation Tutorial DA53T

The slider will press down when stepping the pedal. And slider will stop accordingly when stopping to step the pedal under the Jog Mode.

Operation Tutorial DA53T

Click the blue button to open the Retract Mode. The slider will press down when stepping the pedal.

Operation Tutorial DA53T

And slider will retract upwards when stopping to step the pedal under the Retract Mode.

Operation Tutorial DA53T

Safety Light Curtain

Once an obstruction enters the protection zone.

Operation Tutorial DA53T

The slider stops moving. The control system will also alert immediately.

Operation Tutorial DA53T

Part 7 Switch Off

Step the pedal switch to lower the punch against the die.

Operation Tutorial DA53T

Press the stop button.

Operation Tutorial DA53T

Switch off the pump.

Operation Tutorial DA53T

Press the emergency stop buttons.

Operation Tutorial DA53T

Turn off the power switch.

Operation Tutorial DA53T

Above is the detailed operation tutorial of our Smart Press Brake DA-53T. If you have more problems during actual operations, kindly leave messages on our background to communicate with us and HARSLE will be here with you.
