WE67K
HARSLE
8462219000
SKU: | |
---|---|
Availability: | |
Quantity: | |
Product Description
40-ton CNC mini press brake machine with DA-53T, 1500mm hydraulic bending machine. X+R Axis CNC backgauge. YASKAWA Servo drive and Schneider electric parts.One-key release fast clamps.
DA-53T Controller
● “Hot-Key” touch navigation ● 10.1" high resolution colour TFT ● Up to 4 axes (Y1,Y2 + 2 aux. axes) ● Crowning control ● Tool / material / product library ● Servo and frequency inverter control ● Advanced Y-axis control algorithms for closed-loop as well as open-loop valves ● TandemLink (option) ● USB memory stick interfacing ● Profile-T offline software |
CNC backgauge
X+R
Technical Parameters
No. | Item | Unit | 80T/1500 |
1 | Bending force | kN | 800 |
2 | Bending length | mm | 1500 |
3 | Columns distance | mm | 1200 |
4 | Throat depth | mm | 300 |
5 | Cylinder stroke(Y1,Y2) | mm | 150 |
6 | Die loading height(Daylight) | mm | 380 |
7 | Y-axis down speed | mm/sec | 150 |
8 | Y-axis return speed | mm/sec | 120 |
9 | Y-axis wording speed | mm/sec | 4~15(adjustable) |
10 | Y-axis accuracy | mm | ±0.01 |
11 | Work-piece linearity | mm | 0.3/m |
12 | Max.Back gauge distance | mm | 500 |
13 | X-axis and R-axis speed | mm/sec | 400 |
14 | X-axis and R-axis accuracy | mm | ±0.01 |
15 | Front sliding arms | pcs | 2 |
16 | Bending angle accuracy | (') | ≤±18 |
17 | Back gauge finger stopper | pcs | 4 |
18 | Main motor | KW | 5.5 |
19 | Dimension | Length(mm) | 1700 |
Width(mm) | 1450 | ||
Height(mm) | 2200 | ||
20 | Weight | kg | 3500 |
